High performance COB curing module, high efficiency, more than 25000 hours of service life;International standard DMX512 control mode, PWM digital system dimming, good linearity, no jitter;Constant voltage and constant current drive, the relevant optical indicators remain stable, dimming process will not produce changes. It is suitable for all stages, TV stations and professional venues.
Power supply: AC100-240V~ 50/60Hz
Power: 300W, power factor PF≥0.98
Light source: 96 *3W LED (24R, 24G, 24B, 24W)
Source life: ≥50000 hours
Luminous flux: 17600lm
Color temperature: 3000K-8000K linear adjustment
Lens: bead lens
Beam Angle: 110°
Dimming: 0-100% linear dimming
Stroboscopic effect: 0-20 times/second
Control mode: DMX512
Tilt Angle: +/ -90 °
Heat dissipation: new and reliable air convection cooling mute mode, no fan, low noise
Housing: Aluminum Alloy
Color of lamp body: black
IP Rating: IP65
Working environment temperature: 0℃-40℃
Size: 517×221×306 mm(W×D×H)
Weight: 17.8 kg
